Air Mizer Rotary Valve Shaft Seal

The AM Rotary Valve shaft seal offers effective sealing for rotary valves.

The compact design is custom engineered to fit the unique, tight spaces in rotary valve applications and provide superior, permanent protection against product leakage.

Air Mizer Rotary Valve shaft seal engineering drawing

Features and Benefits

Non-Contacting Design – does not use contact to create a seal, therefore has no wearing parts and lasts the lifetime of the equipment
Internal Chamber – pressurizes sealing medium and directs it to the throttle
Throttle – pressurizes and efficiently distributes the sealing medium evenly around the circumference of the shaft, creating a positive purge and accommodates radial run-out and axial movement simultaneously
Compact Design – 1.125 in. (28.58 mm) overall length (OAL) to fit within tight spaces
Multiple Flange Options – provides flexibility to fit unique rotary valves designs

Technical Data

Standard Material – Bearing Bronze, Ertalyte
Standard Overall Length – 28.58 mm (1.125 in.)
Axial Movement – unlimited
Radial Movement – 1.90 mm (0.075 in.)
Temperature Range – 0°C (32°F) to 99°C (210°F)
Speed – 400 SFPM
Product Pressure – 0.34 bar (5 psi)
Shaft Size – 25.40 mm (1 in.) to 152 mm (6 in.)

Consult an Inpro/Seal representative for operating conditions outside of limits shown.

Typical Applications

Rotary Valves
