AM CEMA Shaft Seal

The AM CEMA shaft seal is a complete shaft sealing system for CEMA Screw Conveyors.

The Inpro/Seal AM CEMA is an Air Mizer shaft seal design specifically for CEMA (Conveyor Equipment Manufacturers Association) Screw Conveyors to eliminate product loss and contamination. Designed to last the lifetime of your equipment, the unique design of the AM CEMA shaft seal is maintenance free with no wearing parts. The rotor fully articulates to accommodate radial run-out and angular misalignment simultaneously.

Air Mizer CEMA shaft seal engineering drawing

Technical Data

  • Standard Material – Aluminum, Ertalyte
  • Axial Movement – 0.38 mm (0.015 in.)
  • Radial Movement – 3.00 mm (0.118 in.)
  • Temperature Range – 0°C (32°F) to 99°C (210°F)
  • Product Pressure – 2.07 bar (30 psi)
  • Shaft Size – 25.40 mm (1.000 in.), 38.10 mm (1.500 in.), 50.80 mm (2.000 in.), 61.93 mm (2.438 in.), 76.20 mm (3.000 in.), 87.33 mm (3.438 in.)

Consult an Inpro/Seal representative for operating conditions outside of limits shown.

Inpro/Seal AM CEMA shaft seals are engineered to fit standard CEMA screw conveyor dimensions.

Shaft Diameter

Overall Length

Flange Width

Max Temp

Part Number

1.000 in

1.750 in.

4.250 in.

210°F

9975-EERP-82276-5

1.000 in

1.750 in.

4.250 in.

400°F

9975-ECPG-82276-5

1.500 in

1.750 in.

5.375 in.

210°F

9975-EERP-82277-5

1.500 in

1.750 in.

5.375 in.

400°F

9975-ECPG-82277-5

2.000 in

1.750 in.

6.500 in.

210°F

9975-EERP-82278-5

2.000 in

1.750 in.

6.500 in.

400°F

9975-ECPG-82278-5

2.438 in.

1.750 in.

7.375 in.

210°F

9975-EERP-82279-5

2.438 in.

1.750 in.

7.375 in.

400°F

9975-ECPG-82279-5

3.000 in.

1.750 in.

7.750 in.

210°F

9975-EERP-82280-5

3.000 in.

1.750 in.

7.750 in.

400°F

9975-ECPG-82280-5

3.438 in.

1.750 in.

9.250 in.

210°F

9975-EERP-82281-5

3.438 in.

1.750 in.

9.250 in.

400°F

9975-ECPG-82281-5

4.438 in.

1.750 in.

10.875 in.

210°F

9975-EERP-82282-5

4.438 in.

1.750 in.

10.875 in.

400°F

9975-ECPG-82282-5
